Ais-140 protocol

Integration level: params
Automotive Industry Standard 140 (AIS 140) is a set of standards published by the Automotive Research Association of India (ARAI).
flespi parses the Ais-140 protocol messages into a JSON object with the fields listed below in the Parameters tab.
ain
number
volts
Voltage on the analog input
alarm.event
boolean
Alarm event triggered
battery.level
number
percentage
Internal battery level
battery.low.status
boolean
Battery low status
battery.voltage
number
volts
Internal battery voltage
channel.id
number
ID of channel that received a message
device.id
number
ID of device that received a message
device.name
string
Name of device that received a message
device.type.id
number
ID of device type of device that received a message
din
number
Digital inputs bitmask
dout
number
Digital outputs bitmask
engine.ignition.status
boolean
Engine ignition status
event.seqnum
number
Unique event sequence number
external.powersource.status
boolean
External power source connection status
external.powersource.voltage
number
volts
External power voltage
gsm.cellid
number
GSM base station ID
gsm.lac
number
GSM location area code
gsm.mcc
string
GSM mobile country code
gsm.mnc
string
GSM mobile network code
gsm.network.name
string
GSM operator name
gsm.signal.dbm
number
dbm
Strength of GSM signal
harsh.acceleration.event
boolean
Harsh acceleration detected
harsh.braking.event
boolean
Harsh braking detected
harsh.cornering.event
boolean
Harsh cornering detected
ident
string
Device unique identificator and optional password
message.buffered.status
boolean
Black box message
overspeeding.event
boolean
Overspeeding detected
peer
string
IP:port from which device connecting to the channel
position.altitude
number
meters
Altitude value for position
position.direction
number
degrees
Heading angle at position detection moment
position.hdop
number
Horizontal dilution of precision
position.latitude
number
degrees
Latitude coordinate value
position.longitude
number
degrees
Longitude coordinate value
position.pdop
number
Position dilution of precision
position.satellites
number
Quantity of satellites used to calculate coordinates for given position information
position.speed
number
km/h
Instant speed at position detection moment
position.valid
boolean
Is position information accurate and valid for given timestamp
protocol.id
number
ID of protocol
server.timestamp
number
seconds
Timestamp when server received a message
sos.button.status
boolean
Sos (emergency) button status: true - connected, false - disconnected (tampered)
tilt.status
boolean
Device tilt status (true - device is tilted, false - device is in normal position)
timestamp
number
seconds
Message timestamp
vehicle.mileage
number
km
Total calculated mileage
vehicle.registration.number
string
Vehicle registration number

Automotive Industry Standard 140 (AIS 140) is a set of standards published by the Automotive Research Association of India (ARAI). It is used for vehicle tracking systems, camera surveillance systems, and emergency request buttons. The government has directed every state’s public transport department to make sure that all passenger-carrying buses conform to the AIS 140 guidelines by April 1, 2018.
