Fleetboard protocol
Protocol used to fetch vehicle position data from Daimler Fleetboard Platform.
flespi parses the Fleetboard protocol messages into a JSON object with the
fields listed below in the Parameters tab.
Fetch vehicles position information to a channel from Fleetboard platform by Daimler.
To establish the connection between Fleetboard and flepsi, create a channel of "fleetboard" type in the flespi panel and specify the fleet name, login, and password used within Fleetboard.
adblue.consumed
number
liters
Total adBlue consumed
p725:Header/p725:States/p725:State[TotalAddBlueUsed]
can.adblue.level
number
percentage
AdBlue (diesel exhaust fluid) level read from CAN
p725:Header/p725:States/p725:State[AddBlueLevel]
can.ambient.air.temperature
number
celsius
CAN ambient air temperature
p725:Header/p725:Position/p725:TemperatureOutside
can.brake.wear.front.left
number
Front left brake lining wear, percentage
Command: can.brake.wear.front.left
can.brake.wear.front.right
number
Front right brake lining wear, percentage
Command: can.brake.wear.front.right
can.brake.wear.max
number
Maximum brake wear across all wheels, percentage
Command: can.brake.wear.max
can.brake.wear.rear.left
number
Rear left brake lining wear, percentage
Command: can.brake.wear.rear.left
can.brake.wear.rear.right
number
Rear right brake lining wear, percentage
Command: can.brake.wear.rear.right
can.coolant.level.warning.count
number
Count of cooling water level warnings
Command: can.coolant.level.warning.count
can.dpf.state
number
Diesel particulate filter state
Command: can.dpf.state
can.dpf.zone
number
Diesel particulate filter operating zone
Command: can.dpf.zone
can.engine.oil.shortfall
number
Engine oil level deficit
Command: can.engine.oil.shortfall
can.engine.oil.shortfall.state
number
Engine oil level status
Command: can.engine.oil.shortfall.state
can.inside.air.temperature
number
celsius
Inside air temperature
p725:Header/p725:Position/p725:TemperatureInside
can.power.steering.oil.level
number
Power steering fluid level
Command: can.power.steering.oil.level
can.vehicle.battery.charging.status
boolean
Vehicle battery charging status get from CAN Bus
p725:Header/p725:Position/p725:ChargingStatus
can.vehicle.battery.level
number
percentage
CAN-bus reported vehicle battery level for EV or HEV
p725:Header/p725:Position/p725:BatteryLevel
can.vehicle.battery.remaining.range
number
km
Vehicle battery remaining range, read from CAN
p725:Header/p725:Position/p725:RemainingRange
can.washing.water.reserve
number
Windshield washer fluid reserve
Command: can.washing.water.reserve
channel.id
number
ID of channel that received a message
device.id
number
ID of device that received a message
device.name
string
Name of device that received a message
device.type.id
number
ID of device type of device that received a message
driver.id
string
Driver identification card id
Command: driver.id
engine.ignition.status
boolean
Engine ignition or ACC status
p725:Header/p725:States/p725:State[Ignition],
p725:Header/p725:States/p725:State[Motor]
p725:Header/p725:States/p725:State[Motor]
faulty.bulbs.count
number
Number of faulty vehicle bulbs
Command: faulty.bulbs.count
fuel.consumed
number
liters
Fuel volume totally consumed by vehicle
p725:Header/p725:States/p725:State[TotalFuelUsed]
fuel.consumption.current
number
Current fuel consumption rate
Command: fuel.consumption.current
fuel.level
number
percentage
Fuel level percentage
p725:Header/p725:States/p725:State[FuelLevel]
fuel.quality
number
Fuel quality status
Command: fuel.quality
ident
string
Device unique identifier like serial number, IMEI, etc
maintenance.next.activity
number
Type of next scheduled maintenance
Command: maintenance.next.activity
maintenance.next.date
number
Date of next scheduled maintenance
Command: maintenance.next.date
message.type
string
Message type
Command: message.type
oil.quality
number
Engine oil quality status
Command: oil.quality
oil.viscosity
number
Engine oil viscosity rating
Command: oil.viscosity
peer
string
IP:port from which device connecting to the channel
position.direction
number
degrees
Heading angle at position detection moment
p725:Header/p725:Position/p725:Course
position.latitude
number
degrees
Latitude coordinate value
p725:Header/p725:Position/p725:Lat
position.longitude
number
degrees
Longitude coordinate value
p725:Header/p725:Position/p725:Long
position.speed
number
km/h
Instant speed at position detection moment
p725:Header/p725:Position/p725:Speed
position.timestamp
number
seconds
Timestamp when coordinates where calculated
p725:Header/p725:Position
position.valid
boolean
Is position information accurate and valid for given timestamp
p725:Header/p725:Position/p725:GPSStatus
protocol.id
number
ID of protocol
segment.average.speed
number
km/h
Average speed for time report
Performance Analysis: p725:AvgValues/p725:Speed
segment.average.vehicle.battery.energy.consumed
number
kWh/100km
Average electric energy consumption from vehicle battery during the segment
Performance Analysis: p725:AvgValues/p725:ConsumptionKwh
segment.average.vehicle.battery.energy.recuperated
number
kWh/100km
Average electric energy recuperation into vehicle battery during the segment
Performance Analysis: p725:AvgValues/p725:Recuperation
segment.average.weight
number
kg
Average vehicle weight during the segment
Performance Analysis: p725:AvgValues/p725:Weight
segment.braking.distance
number
km
Distance, travelled while brake pedal was pressed since last record
Performance Analysis: p725:BrakingDistance
segment.coasting.distance
number
km
Distance traveled while coasting during the segment
Performance Analysis: p725:TotalCoastingDistance
segment.cruise.control.distance
number
km
Distance travelled under cruise control during the last segment
Performance Analysis: p725:CruiseControlDistance
segment.high.speed.distance.ratio
number
percentage
Percentage of total distance traveled at speed exceeding 85% of maximum speed during the segment
Performance Analysis: p725:SpeedOver85PerTotalDistance
segment.id
string
Segment or trip identifier from telematics provider
Performance Analysis: p725:ID
segment.idle.count
number
Number of stops during the segment
Performance Analysis: p725:NrOfStops
segment.idle.time
number
seconds
Time the vehicle was idle with engine off during the segment
Performance Analysis: p725:StopTimeEngineOff
segment.moving.time
number
seconds
Duration of moving during the segment
Performance Analysis: p725:MovingTime
segment.retarder.torque.distance
number
km
Distance driven between two consecutive records when retarder torque was above zero.
Performance Analysis: p725:RetarderBrakingDistance
segment.start.timestamp
number
seconds
Segment or trip start timestamp
Performance Analysis: p725:Period/p725:Begin
segment.stop.timestamp
number
seconds
Segment or trip end timestamp
Performance Analysis: p725:Period/p725:End
segment.vehicle.battery.energy.consumed
number
kWh
Electric energy consumed from vehicle battery during the segment
Performance Analysis: p725:Consumption/p725:TotalConsumptionKwh
segment.vehicle.battery.energy.recuperated
number
kWh
Electric energy recuperated into vehicle battery during the segment
Performance Analysis: p725:Recuperation
segment.vehicle.mileage
number
km
Segment mileage
Performance Analysis: p725:TotalDistance
server.timestamp
number
seconds
Timestamp when server received a message
state.of.order.management
number
Order management state code from last position
Command: state.of.order.management
state.of.time.management
number
Time management state code from last position
Command: state.of.time.management
state.of.vehicle
number
Vehicle state code from last position
Command: state.of.vehicle
timestamp
number
seconds
Message timestamp
p725:Header/p725:VehicleTimestamp
total.vehicle.weight
number
kg
Total vehicle weight
p725:Header/p725:States/p725:State[TruckWeight]
transmission.oil.quality
number
Transmission oil quality status
Command: transmission.oil.quality
vehicle.id
number
Vehicle ID connected with the device
p725:Header/p725:VehicleID
vehicle.mileage
number
km
Total calculated mileage
p725:Header/p725:Position/p725:KM
vehicle.registration.date
number
Vehicle registration date
Command: vehicle.registration.date
vehicle.type.name
number
Vehicle type name
Command: vehicle.type.name
