September 10–11, 2025 / Vilnius, LithuaniaOrbcomm-push protocol
Orbcomm Push Protocol for Satellite Tracking Devices.
flespi parses the Orbcomm-push protocol messages into a JSON object with the
fields listed below in the Parameters tab.
The ORBCOMM Platform supports Data Subscription service that allows clients to receive device messages to their system in a near real-time basis.
The data arriving into the platform is Pushed to clients using an HTTPS POST.
account.name
string
Account the device belongs to
battery.state
string
Battery state
battery.voltage
number
volts
Internal battery voltage
channel.id
number
ID of channel that received a message
device.firmware.version
string
Firmware revision
device.id
number
ID of device that received a message
device.installed.timestamp
number
seconds
Device installed timestamp
device.model
string
Device model ID string
device.name
string
Name of device that received a message
device.self.name
string
Device name reported by the device
device.type.id
number
ID of device type of device that received a message
event.timestamp
number
seconds
Timestamp of the event
freezer.air.temperature
number
celsius
Freezer ambient air temperature
geofence.in.duration
number
seconds
Duration inside geofence
geofence.name
string
Geofence name
geofence.out.duration
number
seconds
Duration outside geofence
geofence.status
boolean
Geofence entered status
geofence.type.enum
number
Geofence type enum
gps.satellites.status
boolean
GPS positioning system status
ident
string
Device unique identifier like serial number, IMEI, etc
max.x.acceleration
number
g
Harsh acceleration event max accelerometer value on X-axis
max.y.acceleration
number
g
Harsh acceleration event max accelerometer value on Y-axis
max.z.acceleration
number
g
Harsh acceleration event max accelerometer value on Z-axis
message.id
number
Message unique ID
message.type
string
Message type
movement.status
boolean
Current movement state
movement.type
string
Movement type
peer
string
IP:port from which device connecting to the channel
position.address
string
Location Address
position.city
string
Location City
position.country
string
Location Country
position.direction
number
degrees
Heading angle at position detection moment
position.latitude
number
degrees
Latitude coordinate value
position.longitude
number
degrees
Longitude coordinate value
position.state
string
Location State
position.zip
string
Location Zip code
protocol.id
number
ID of protocol
sensor.battery.low.status
boolean
Sensor battery status, true - battery low, false - battery ok
sensor.battery.voltage
number
volts
Sensor battery voltage
sensor.temperature
number
celsius
Temperature sensor value
server.timestamp
number
seconds
Timestamp when server received a message
solar.panel.charging.status
boolean
Solar panel charging device
timestamp
number
seconds
Message timestamp
