Sucre Lee Tracking Devices Protocol.
flespi parses the Sucre-lee protocol messages into a JSON object with the fields listed below in the Parameters tab.
Access parsed data via MQTT & REST API Send commands to configure devices
All protocols
Usage specifics Parameters (63) Commands (1) Devices (6)

Sucre Lee Tracking Devices Protocol

Name
Type
Unit
Description
Sources
alarm.code
number
Protocol-specific alarm code number
Protocol Number 0x26,
Protocol Number 0x32
alarm.event
boolean
Alarm event triggered
Protocol Number 0x26,
Protocol Number 0x32
battery.charging.status
boolean
Battery charging status
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
battery.level
number
percentage
Internal battery level
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
battery.low.alarm
boolean
Battery low alarm event
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
can.air.condition.status
boolean
CAN air conditioning is on
Protocol Number 0x94 with Information Type 0x0A
channel.id
number
ID of channel that received a message
crash.event
boolean
Crash event detected
Protocol Number 0x26,
Protocol Number 0x32
defense.active.status
boolean
Defense activated status
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
device.id
number
ID of device that received a message
device.imei
string
IMEI of the device
Protocol Number 0x94 with Information Type 0x0A
device.name
string
Name of device that received a message
device.type.id
number
ID of device type of device that received a message
din
number
Digital inputs bitmask
Protocol Number 0x94 with Information Type 0x05,
Protocol Number 0x94 with Information Type 0x0A
door.alarm
boolean
Door alarm event
Protocol Number 0x26,
Protocol Number 0x32
engine.blocked.status
boolean
Engine blocked status (fuel cutoff relay), true - engine is blocked, false - engine isn't blocked
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
engine.ignition.status
boolean
Engine ignition or ACC status
Protocol Number 0x13,
Protocol Number 0x22,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32
external.powersource.status
boolean
External power source connection status
Protocol Number 0x26,
Protocol Number 0x32
external.powersource.voltage
number
volts
External power voltage
Protocol Number 0x13,
Protocol Number 0x94 with Information Type 0x00
geofence.status
boolean
Geofence entered status
Protocol Number 0x26,
Protocol Number 0x32
gnss.realtime.status
boolean
True - GNSS realtime positioning, False - differential positioning
Protocol Number 0x22,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32
gnss.signal.status
boolean
True - GNSS signal is present, False - GNSS signal is lost
Protocol Number 0x26,
Protocol Number 0x32
gnss.status
boolean
GNSS receiver on/off status
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
gsm.cellid
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) base station ID
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32,
Protocol Number 0x34
gsm.jamming.event
boolean
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal jamming detected
Protocol Number 0x26,
Protocol Number 0x32
gsm.lac
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) location area code
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32,
Protocol Number 0x34
gsm.mcc
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) country code
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32,
Protocol Number 0x34
gsm.mnc
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) code
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32,
Protocol Number 0x34
gsm.network.type
string
The type of the Mobile network the device is currently registered to
Protocol Number 0x94 with Information Type 0x0B
gsm.signal.dbm
number
dbm
Strength of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal
Protocol Number 0x24,
Protocol Number 0x34
gsm.signal.level
number
percentage
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal strength level
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
gsm.sim.iccid
string
Integrated Circuit Card Id of SIM card of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...)
Protocol Number 0x94 with Information Type 0x0A
gsm.sim.imsi
string
IMSI of SIM card of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...)
Protocol Number 0x94 with Information Type 0x0A
gsm.timing.advance
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) timing advance
Protocol Number 0x24,
Protocol Number 0x34
harsh.acceleration.event
boolean
Harsh acceleration detected
Protocol Number 0x26,
Protocol Number 0x32
harsh.braking.event
boolean
Harsh braking detected
Protocol Number 0x26,
Protocol Number 0x32
harsh.cornering.event
boolean
Harsh cornering detected
Protocol Number 0x26,
Protocol Number 0x32
ident
string
Device unique identifier like serial number, IMEI, etc
language
string
Language used on the device
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
main.power.low.status
boolean
Main power low status
Protocol Number 0x26,
Protocol Number 0x32
message.buffered.status
boolean
Black box message
Protocol Number 0x31
motion.alarm
boolean
Motion alarm
Protocol Number 0x26,
Protocol Number 0x32
overspeeding.event
boolean
Overspeeding detected
Protocol Number 0x26,
Protocol Number 0x32
peer
string
IP:port from which device connecting to the channel
position.altitude
number
meters
Altitude value for position
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32
position.direction
number
degrees
Heading angle at position detection moment
position.latitude
number
degrees
Latitude coordinate value
Protocol Number 0x22,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32
position.longitude
number
degrees
Longitude coordinate value
Protocol Number 0x22,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32
position.satellites
number
Quantity of satellites used to calculate coordinates for given position information
position.speed
number
km/h
Instant speed at position detection moment
Protocol Number 0x22,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32
position.valid
boolean
Is position information accurate and valid for given timestamp
Protocol Number 0x22,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32
power.cut.alarm
boolean
External power cut-off alarm event
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
power.status
boolean
True - power is ON, False - power is OFF
Protocol Number 0x26,
Protocol Number 0x32
protocol.id
number
ID of protocol
protocol.number
number
Protocol number
remove.alarm
boolean
Remove alarm
Protocol Number 0x26,
Protocol Number 0x32
rollover.event
boolean
Roll over event detected
Protocol Number 0x26,
Protocol Number 0x32
server.timestamp
number
seconds
Timestamp when server received a message
shutdown.alarm
boolean
Shutdown alarm event
Protocol Number 0x26,
Protocol Number 0x32
sos.alarm
boolean
SOS alarm triggerred
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
timestamp
number
seconds
Message timestamp
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26,
Protocol Number 0x31,
Protocol Number 0x32,
Protocol Number 0x34
vehicle.mileage
number
km
Total calculated mileage
Protocol Number 0x22,
Protocol Number 0x31
vibration.alarm
boolean
Vibration alarm event
Protocol Number 0x13,
Protocol Number 0x26,
Protocol Number 0x32
Title
Name
Description
Properties
Custom Command
custom
Send custom command to device
payload: Command payload
Enable LED light
{"payload":"LED,ON#"}
Device
Manufacturer
Tags
Sucre Lee SL22
Sucre Lee
battery
sos
vehicle
Sucre Lee SL24
Sucre Lee
battery
sos
vehicle
Sucre Lee SL28
Sucre Lee
battery
sos
vehicle
Sucre Lee SL42 4G
Sucre Lee
battery
sos
vehicle
Sucre Lee SL44 4G
Sucre Lee
battery
sos
vehicle
Sucre Lee SL48 4G
Sucre Lee
battery
sos
vehicle
