Wiatag protocol
Protocol used by the Wiatag mobile application designed by Gurtam for Android and IOS devices. The app transforms any smartphone into a full-scale GPS tracker.
flespi parses the Wiatag protocol messages into a JSON object with the
fields listed below in the Parameters tab.
Wiatag protocol is used by the WiaTag mobile application (designed by Gurtam) for Android and iOS devices.
Once you install the app on your smartphone and run it, follow these configuration steps to get started.
- Sign in to the app: switch to Wialon Local tab, enter ident of your flespi WiaTag device into Unique ID field, and host and port of your flespi WiaTag channel into the Host and Port fields as shown below (optional: if you have configured Device password for your flespi WiaTag device, then enter this password into the Password field):
- Use the Tracking toggle to enable/disable GPS tracking for your phone.
- Click the gear icon in the top right corner to open Settings.
alarm.event
boolean
Alarm event triggered
battery.level
number
percentage
Internal battery level
channel.id
number
ID of channel that received a message
custom
any
Any custom parameter
device.id
number
ID of device that received a message
device.name
string
Name of device that received a message
device.type.id
number
ID of device type of device that received a message
driver.message
string
Driver text message content
gsm.cellid
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) base station ID
gsm.lac
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) location area code
gsm.mcc
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) country code
gsm.mnc
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) code
gsm.network.name
string
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) operator name
gsm.signal.level
number
percentage
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal strength level
ident
string
Device unique identifier like serial number, IMEI, etc
media
boolean
Message contain media file
media.image
object
Image file in media storage
peer
string
IP:port from which device connecting to the channel
position.accuracy
number
meters
Position data accuracy in meters
position.altitude
number
meters
Altitude value for position
position.direction
number
degrees
Heading angle at position detection moment
position.latitude
number
degrees
Latitude coordinate value
position.longitude
number
degrees
Longitude coordinate value
position.satellites
number
Quantity of satellites used to calculate coordinates for given position information
position.speed
number
km/h
Instant speed at position detection moment
protocol.id
number
ID of protocol
server.timestamp
number
seconds
Timestamp when server received a message
timestamp
number
seconds
Message timestamp
Properties
Send Message
message
Send message to WiaTag chat
payload: Message
Send Application Settings
settings
Send settings json to WiaTag application
payload: Settings json
Take a photo
take_photo
Take a photo
