OsmAnd

software tracker

OsmAnd turns any smartphone into a GPS tracker (Android). It reports location to your own or a hosted server with selected time intervals.

With the osmand channel, you can get the position data from your OsmAnd application straight into flespi.

In order to receive data from your OsmAnd application, you need to activate Online tracking in the TripRecording plugin settings.

In the Web Address field, you need to specify the address of the flespi channel and add the desired parameters. You also need to add the id parameter to identify the device.

Example of a Web Address field:

https://ch*********.flespi.gw:****?lat={0}&lon={1}&timestamp={2}&hdop={3}&latitude={4}&speed={5}&id=test_id


Please note that by default, your channel will start an HTTPS server, so use "https://" prefix for the channel uri when configuring your osmand application on smartphone.
Protocol: osmand Manufacturer: OsmAnd Change log: osmand
Usage specifics
Parameters (15)
OsmAnd
Flespi parses telemetry data from your OsmAnd into a standardized JSON and lets you send commands to OsmAnd via API.

Here’s the like of JSON you get

{
    "ident": "352625333222111",
    "position.altitude": 273.61,
    "position.hdop": 0.7,
    "position.latitude": 49.069782,
    "position.longitude": 28.632826,
    "position.satellites": 18,
    "server.timestamp": 1650636570.426424,
    "timestamp": 1650636570.426424,
    "device.type.id": "OsmAnd",
    "channel.id": 1111,
    "protocol.id": "osmand"
    "engine.ignition.status": true
    ...
}

How to consume this nice JSON

The easiest way is to make a REST API request like this
curl -X GET  --header 'Authorization: FlespiToken XXX' 'https://flespi.io/gw/devices/<device id>/messages'
Explore REST API Show more ways to consume dataHow to connect my OsmAnd to flespi

You can also

Modify messages

Add or remove parameters, inject data from LBS and reverse-geocoding services, etc.
Learn what plugins can do

Aggregate data

Determine trips and stops, catch events, detect geofence ins/outs, and more.
Learn about flespi analytics capabilities
Name
Type
Unit
Description
Sources
channel.id
number
ID of channel that received a message
device.id
number
ID of device that received a message
device.name
string
Name of device that received a message
device.type.id
number
ID of device type of device that received a message
ident
string
Device unique identifier like serial number, IMEI, etc
peer
string
IP:port from which device connecting to the channel
position.altitude
number
meters
Altitude value for position
altitude
position.direction
number
degrees
Heading angle at position detection moment
bearing
position.hdop
number
Horizontal dilution of precision
hdop
position.latitude
number
degrees
Latitude coordinate value
lat
position.longitude
number
degrees
Longitude coordinate value
lon
position.speed
number
km/h
Instant speed at position detection moment
speed
protocol.id
number
ID of protocol
server.timestamp
number
seconds
Timestamp when server received a message
timestamp
number
seconds
Message timestamp
timestamp
