Atlantasys protocol

Protocol used by GPS tracking devices manufactured by Atlanta Systems headquartered in India.
flespi parses the Atlantasys protocol messages into a JSON object with the fields listed below in the Parameters tab.

To connect your tracker using the Atlanta Systems protocol, you need to have a atlantasys channel created first.

Point your tracker to the channel's domain name:port via SMS or configuration tool provided by the vendor.

Then create a device instance for your tracker and use a 15-character IMEI (usually specified on the tracker casing) in the ident field.

Use the Toolbox tab on the device screen to check if the messages are coming.

arm.status
boolean
Device arm status (true - device armed, false - device disarmed)
battery.voltage
number
volts
Internal battery voltage
channel.id
number
ID of channel that received a message
device.id
number
ID of device that received a message
device.name
string
Name of device that received a message
device.temperature
number
celsius
Temperature of device
device.type.id
number
ID of device type of device that received a message
door.open.status
boolean
Door open status
engine.ignition.status
boolean
Engine ignition or ACC status
external.powersource.status
boolean
External power source connection status
external.powersource.voltage
number
volts
External power voltage
gsm.cellid
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) base station ID
gsm.lac
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) location area code
gsm.mcc
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) country code
gsm.mnc
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) code
gsm.signal.level
number
percentage
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal strength level
harsh.acceleration.event
boolean
Harsh acceleration detected
harsh.braking.event
boolean
Harsh braking detected
ibutton.code
string
Hexadecimal code of connected iButton
ident
string
Device unique identifier like serial number, IMEI, etc
lls.frequency
number
LLS (Liquid level sensor) sensor frequency
lls.temperature
number
celsius
LLS (Liquid level sensor) fuel temperature
lls.value
number
LLS (Liquid level sensor) fuel value
magnetic.declination
number
degrees
The angle on the horizontal plane between magnetic north and true north
message.buffered.status
boolean
Black box message
movement.status
boolean
Current movement state
operating.mode
string
Protocol-specific device operating mode string
payload.text
string
Text Payload received from device
peer
string
IP:port from which device connecting to the channel
position.direction
number
degrees
Heading angle at position detection moment
position.latitude
number
degrees
Latitude coordinate value
position.longitude
number
degrees
Longitude coordinate value
position.speed
number
km/h
Instant speed at position detection moment
position.valid
boolean
Is position information accurate and valid for given timestamp
protocol.id
number
ID of protocol
sensor.temperature
number
celsius
Temperature sensor value
server.timestamp
number
seconds
Timestamp when server received a message
sleep.mode.status
boolean
Device is in sleep mode
sos.alarm
boolean
SOS alarm triggerred
timestamp
number
seconds
Message timestamp
vehicle.mileage
number
km
Total calculated mileage
Properties
Custom command
custom
Send custom command to device without waiting for response, Scheme: "$MSG,&". You have to specify payload only
