Concox protocol

Integration level: params + settings
Protocol used by GPS tracking devices manufactured by Shenzhen Concox headquartered in China.
flespi parses the Concox protocol messages into a JSON object with the fields listed below in the Parameters tab.
abnormal.alarm
boolean
Abnormal alarm
airplane.mode.alarm
boolean
Airplane mode enabled alarm event
alarm.button.pressed.event
boolean
Button to upload alarm message to the platform was pressed
alarm.event
boolean
Alarm event triggered
automatic.cruise.status
boolean
Automatic cruise
battery.charging.status
boolean
Battery charging status
battery.fault.status
boolean
Battery fault status
battery.level
number
percentage
Internal battery level
battery.low.alarm
boolean
Battery low alarm event
battery.low.status
boolean
Battery low status
battery.temperature
number
celsius
Battery temperature
battery.voltage
number
volts
Internal battery voltage
boot.reason
number
Boot reason
brake.handle.fault.status
boolean
Brake handle fault status
braking.status
boolean
Braking status
can.average.speed
number
km/h
Vehicle average speed, read from CAN
can.brake.pedal.status
boolean
Footbrake pedal is depressed status, read from CAN
can.central.lock.status
boolean
CAN central lock is locked
can.driver.door.status
boolean
CAN driver door is opened
can.engine.ignition.status
boolean
CAN engine ignition status
can.engine.rpm
number
rpm
Engine RPM read from CAN
can.engine.status
boolean
Engine is ON status, read from CAN
can.fuel.consumption.distance
number
liters/100km
Fuel consumption read from CAN
can.fuel.volume
number
liters
CAN fuel volume
can.handbrake.status
boolean
CAN handbrake is pulled up
can.hood.status
boolean
CAN hood is opened
can.left.front.tyre.pressure.status
boolean
Left front tyre pressure is normal
can.left.rear.tyre.pressure.status
boolean
Left rear tyre pressure is normal
can.left.turn.light.status
boolean
Left turn light is ON status, read from CAN
can.passenger.door.status
boolean
CAN passenger door is opened
can.rear.left.door.status
boolean
CAN rear left door is opened
can.rear.right.door.status
boolean
CAN rear right door is opened
can.right.front.tyre.pressure.status
boolean
Right front tyre pressure is normal
can.right.rear.tyre.pressure.status
boolean
Right rear tyre pressure is normal
can.right.turn.light.status
boolean
Right turn light is ON status, read from CAN
can.small.light.status
boolean
Small light is ON status, read from CAN
can.trunk.status
boolean
CAN trunk is opened
can.vehicle.mileage
number
km
Total vehicle mileage read from CAN
channel.id
number
ID of channel that received a message
charging.status
boolean
Charging status
controller.fault.status
boolean
controller fault status
cover.open.alarm
boolean
Open cover alarm event
crash.event
boolean
Crash event detected
cruise.control.status
boolean
Cruise control status
dashboard.controller.fault.status
boolean
Dashboard controller fault status
defense.active.status
boolean
Defense activated status
device.id
number
ID of device that received a message
device.name
string
Name of device that received a message
device.type.id
number
ID of device type of device that received a message
din
number
Digital inputs bitmask
disassemble.alarm
boolean
Disassemble alarm event
displacement.alarm
boolean
Displacement alarm event
door.alarm
boolean
Door alarm event
door.open.status
boolean
Door open status
driver.message
string
Driver text message content
engine.blocked.status
boolean
Engine blocked status, true - engine is blocked, false - engine isn't blocked
engine.ignition.status
boolean
Engine ignition status
event.enum
number
Event code, full list of codes available at separate table
event.seqnum
number
Unique event sequence number
external.battery.low.alarm
boolean
External battery low alarm event
external.battery.protection.low.alarm
boolean
External battery low protection alarm event
external.powersource.voltage
number
volts
External power voltage
fall.alarm
boolean
Fall alarm event
file.md5
number
MD5 summ of auploaded image returted by image server
file.timestamp
number
Timestamp of file creation
file.type.enum
number
Uploaded file type: 1 - photo, 2 - video
file.upload.status
boolean
Image upload result: true - success, false - failure
geofence.id
number
Geofence ID
geofence.status
boolean
Geofence entered status
gnss.first.fix.event
boolean
GNSS first fix event
gnss.realtime.status
boolean
True - GNSS realtime positioning, False - differential positioning
gnss.satellites
number
Number of GNSS satellites
gnss.signal.status
boolean
True - GNSS signal is present, False - GNSS signal is lost
gnss.status
boolean
GNSS receiver on/off status
gsm.cellid
number
GSM base station ID
gsm.lac
number
GSM location area code
gsm.mcc
string
GSM mobile country code
gsm.mnc
string
GSM mobile network code
gsm.signal.dbm
number
dbm
Strength of GSM signal
gsm.signal.level
number
percentage
GSM signal strength level
gsm.sim.iccid
string
Integrated Circuit Card Id of SIM card
gsm.sim.imsi
string
IMSI of SIM card
gsm.timing.advance
number
GSM timing advance
harsh.acceleration.event
boolean
Harsh acceleration detected
harsh.braking.event
boolean
Harsh braking detected
harsh.cornering.event
boolean
Harsh cornering detected
harsh.turn.left.event
boolean
Harsh left turn detected
harsh.turn.right.event
boolean
Harsh right turn detected
headlight.status
boolean
Headlights status
ident
string
Device unique identificator and optional password
internal.battery.low.alarm
boolean
Internal battery low alarm event
iot.module.fault.status
boolean
IOT module fault status
language.enum
string
Language enum
light.status
boolean
Light status
lock.status
boolean
Lock status
message.buffered.status
boolean
Black box message
mileage
number
km
Mileage
motor.fault.status
boolean
Motor fault status
motor.status
boolean
Motor status: false - idle, true - power output
operating.mode.enum
number
Operating mode
overspeeding.event
boolean
Overspeeding detected
payload.hex
string
HEX Payload received from device
payload.text
string
Text Payload received from device
peer
string
IP:port from which device connecting to the channel
position.altitude
number
meters
Altitude value for position
position.direction
number
degrees
Heading angle at position detection moment
position.hdop
number
Horizontal dilution of precision
position.latitude
number
degrees
Latitude coordinate value
position.longitude
number
degrees
Longitude coordinate value
position.outdated
boolean
Position information is outdated
position.satellites
number
Quantity of satellites used to calculate coordinates for given position information
position.speed
number
km/h
Instant speed at position detection moment
position.timestamp
number
seconds
Timestamp when coordinates where calculated
position.valid
boolean
Is position information accurate and valid for given timestamp
power.cut.alarm
boolean
External power cut-off alarm event
power.status
boolean
True - power is ON, False - power is OFF
protocol.id
number
ID of protocol
protocol.number
number
Protocol number
pseudo.base.station.alarm
boolean
Pseudo base station alarm event
pull.alarm
boolean
Pull alarm event
rear.light.enum
number
Rear light state: 0 - off, 1 - solid, 2 - blink, 3 - breathing
remaining.range
number
km
Current remaining range
rfid.code
string
Hexadecimal code of connected RFID
rtc.timestamp
number
seconds
RTC timestamp
server.timestamp
number
seconds
Timestamp when server received a message
shutdown.alarm
boolean
Shutdown alarm event
sim.change.event
boolean
SIM card is changed event
sleep.mode.alarm
boolean
Sleep mode alarm event
sound.control.alarm
boolean
Sound control alarm event
taillight.state.enum
number
Taillight state: 0 - off, 1 - taillight, 2 - brake light
tamper.alarm
boolean
Tamper alarm event
tamper.button.status
boolean
Tamper button status, false - installed, true - removed
throttle.handle.fault.status
boolean
Throttle handle fault status
throttle.status
boolean
Throttle status
timestamp
number
seconds
Message timestamp
total.mileage
number
km
Total mileage
trip.mileage
number
km
Distance driven since engine start
trip.start.latitude
number
degrees
Trip start latitude coordinate value
trip.start.longitude
number
degrees
Trip start longitude coordinate value
trip.start.timestamp
number
seconds
Timestamp value upon trip start
trip.stop.latitude
number
degrees
Trip stop latitude coordinate value
trip.stop.longitude
number
degrees
Trip stop longitude coordinate value
trip.stop.timestamp
number
seconds
Timestamp value upon trip end
unlock.abnormal.alarm
boolean
Abnormal unlocking alarm event
unlock.failure.alarm
boolean
Unlocking failure alarm event
vehicle.mileage
number
km
Total calculated mileage
vibration.alarm
boolean
Vibration alarm event
visible.satellites
number
Number of visible satellites
voltage.fault.status
boolean
Voltage fault status
wifi.mac.address
string
WiFi MAC address
wifi.signal.strength
number
dbm
WiFi signal strength
Properties
Custom Command
custom
Send custom command to device
payload: Command payload
Cut OFF petrol
{"payload":"RELAY,1#"}

To connect your tracker using the Concox protocol, you need to have a concox channel created first.

Point your tracker to the channel's IP:port via SMS or configuration tool provided by the vendor.

Then create a device instance for your tracker and use a 15-character IMEI (usually specified on the tracker casing) in the ident field.

Use the Toolbox tab on the device screen to check if the messages are coming.

Status messages should start coming right after the connection is established.

If no positional data is coming, make sure to install the tracker properly into the vehicle, configure it, and drive at least for a little bit. Concox trackers are reluctant to send position when not moving. You can then change the tracking parameters on the Settings tab of the device screen.

If the messages in Toolbox are colored red (past) or grey (future), try changing the timezone setting via the SMS command or on the Settings tab of the device screen.

It is possible to configure Jimi Software/Concox devices OTA using the flespi web-based configurator tool. To connect Concox to Wialon or another platform via flespi please read this article.
