Sinocastel IDD-213W

Sinocastel IDD-213W is a 3G OBDII GPS tracker with SAE J1939/J1708 (heavy-duty) compliance. The device features 160mAh backup battery, plug-and-play installation, driving behavior monitoring, remote power off, unplug alarm, engine data, fuel consumption monitoring, and more.

Make your Sinocastel IDD-213W devices a part of any infrastructure by connecting them via flespi telematics hub. Manage the device settings using flespi device management platform. Learn how to configure Sinocastel IDD-213W with flespi.

Protocol: sinocastel Manufacturer: Sinocastel Change log: sinocastel

Usage specifics

Parameters (184)

Settings (1)

Commands (2)

AI Assistant

Here’s the like of JSON you get

{
    "ident": "352625333222111",
    "position.altitude": 273.61,
    "position.hdop": 0.7,
    "position.latitude": 49.069782,
    "position.longitude": 28.632826,
    "position.satellites": 18,
    "server.timestamp": 1650636570.426424,
    "timestamp": 1650636570.426424,
    "device.type.id": "Sinocastel IDD-213W",
    "channel.id": 1111,
    "protocol.id": "sinocastel"
    "engine.ignition.status": true
    ...
}

How to consume this nice JSON

The easiest way is to make a REST API request like this

curl -X GET  --header 'Authorization: FlespiToken XXX' 'https://flespi.io/gw/devices/<device id>/messages'

Explore REST API Show more ways to consume data How to connect my Sinocastel IDD-213W to flespi

How to send commands to Sinocastel IDD-213W?

You can send a specific command. Show all commands

You can use pre-defined settings to send instructions more conveniently. Show all settings

You can also

Modify messages

Add or remove parameters, inject data from LBS and reverse-geocoding services, etc.

Learn what plugins can do

Aggregate data

Determine trips and stops, catch events, detect geofence ins/outs, and more.

Learn about flespi analytics capabilities

Name

Type

Unit

Description

Sources

acceleration.array

array

Array of objects with acceleration data by x, y, and z axis

Protocol ID 0x4003

alarm.event

boolean

Alarm event triggered

Protocol ID 0x4007 with Alarm Type 0x10

alcohol.fuel.percentage

number

percentage

Alcohol fuel percentage

PID 0x2152

can.absolute.fuel.rail.pressure

number

kPa

Absolute fuel rail pressure

PID 0x2159

can.absolute.load

number

percentage

Absolute load value - the normalized value of air mass per intake stroke, read from CAN

PID 0x2143

can.accelerator.pedal.position

number

percentage

Accelerator pedal position read from CAN, index 1 - sensor D, index 2 - sensor E, etc

PID 0x2149,
PID 0x214A,
PID 0x214B

can.adblue.level

number

percentage

AdBlue (diesel exhaust fluid) level read from CAN

PID 0x06E1

can.air.filter.differential.pressure

number

kPa

Air filter differential pressure read from CAN

PID 0x006B

can.ambient.air.temperature

number

celsius

CAN ambient air temperature

PID 0x2146

can.average.fuel.economy

number

km/liters

CAN average fuel economy

PID 0x00B9

can.barometric.pressure

number

kPa

Absolute barometric pressure read from CAN

PID 0x006A,
PID 0x2133

can.battery.voltage

number

volts

Battery voltage read from CAN

PID 0x00A8

can.catalyst.temperature

number

degrees

Catalyst temperature of the corresponding oxygen sensor read from CAN

PID 0x213C,
PID 0x213D,
PID 0x213E,
PID 0x213F

can.central.lock.status

boolean

CAN central lock is locked

Protocol ID 0xB007

can.commanded.egr

number

percentage

Commanded EGR value read from CAN

PID 0x212C

can.control.module.voltage

number

volts

Control module voltage read from CAN

PID 0x2142

can.coolant.filter.differential.pressure

number

kPa

Coolant filter differential pressure read from CAN

PID 0x0070

can.crankcase.pressure

number

kPa

Crankcase pressure read from CAN

PID 0x0065

can.crankcase.pressure.extended

number

kPa

Extended crankcase pressure read from CAN

PID 0x0016

can.cruise.control.speed

number

km/h

Cruise control set speed read from CAN

PID 0x0056

can.direct.fuel.rail.pressure

number

kPa

Fuel rail gauge pressure for diesel or gasoline direct injection

PID 0x2123

can.dpf.inlet.pressure

number

kPa

Pressure before DPF read from CAN

PID 0x0051

can.dtc

array

Diagnostic trouble code array read from CAN

Protocol ID 0x4006,
Protocol ID 0x400B

can.dtc.cleared.engine.time

number

hours

Engine runtime since DTCs cleared, read from CAN

PID 0x214E

can.dtc.cleared.mileage

number

Vehicle mileage since diagnostic trouble codes were cleared, read from CAN

PID 0x2131

can.dtc.cleared.warmups

number

Number of warm-ups since DTCs cleared read from CAN

PID 0x2130

can.egr.error

number

percentage

EGR Error read from CAN

PID 0x212D

can.engine.coolant.level

number

percentage

Engine coolant level read from CAN

PID 0x006F

can.engine.coolant.pressure

number

kPa

Engine coolant pressure

PID 0x006D

can.engine.coolant.temperature

number

celsius

Engine coolant temperature read from CAN

PID 0x006E,
PID 0x2105,
PID 0x2167

can.engine.exhaust.temperature

number

celsius

Engine exhaust temperature read from CAN

PID 0x00AD

can.engine.fuel.rate

number

liters/h

Engine fuel rate read from CAN

PID 0x00B7,
PID 0x215E,
PID 0x4004,
PID 0x4005

can.engine.load.level

number

percentage

Calculated engine load level read from CAN

PID 0x005C,
PID 0x2104,
PID 0x4000,
PID 0x4001

can.engine.motorhours

number

hours

Total engine motorhours (engine work time) read from CAN

PID 0x00F7

can.engine.oil.level

number

percentage

Engine oil level read from CAN

PID 0x0062

can.engine.oil.pressure

number

kPa

CAN Engine oil pressure

PID 0x0064

can.engine.oil.temperature

number

celsius

Engine oil temperature read from CAN

PID 0x00AF,
PID 0x215C

can.engine.revolutions

number

Engine totol revolutions read from CAN

PID 0x00F9

can.engine.rpm

number

rpm

Engine RPM read from CAN

PID 0x00BE,
PID 0x210C,
Protocol ID 0x4001

can.engine.run.time

number

seconds

Run time since engine start read from CAN

PID 0x211F,
PID 0x217F

can.engine.status

boolean

Engine is running status, read from CAN

Protocol ID 0xB007

can.engine.temperature

number

celsius

Engine temperature read from CAN

PID 0x4008,
PID 0x4009

can.equivalence.ratio

number

Fuel-air commanded equivalence ratio read from CAN

PID 0x2144

can.evaporative.purge

number

percentage

Commanded evaporative purge read from CAN

PID 0x212E

can.evap.vapor.pressure

number

EVAP system vapor pressure, read from CAN

PID 0x2132,
PID 0x2154

can.freeze.dtc

string

Diagnostic trouble code from freeze frame, read from CAN

PID 0x2102

can.fresh.water.level

number

percentage

Fresh water level read from CAN

PID 0x4014

can.front.left.door.status

boolean

CAN front left door is opened

Protocol ID 0xB007

can.front.right.door.status

boolean

CAN front right door is opened

Protocol ID 0xB007

can.fuel.consumed

number

liters

Fuel volume totally consumed by vehicle read from CAN

PID 0x00FA

can.fuel.economy

number

km/liters

CAN instantaneous fuel economy

PID 0x00B8

can.fuel.idle.consumed

number

liters

Fuel volume totally consumed during idling state of the vehicle read from CAN

PID 0x00EC,
PID 0x03EC

can.fuel.injection.timing

number

degrees

Fuel injection timing read from CAN

PID 0x215D

can.fuel.level

number

percentage

Fuel level in tank read from CAN

PID 0x0026,
PID 0x0060,
PID 0x212F,
PID 0x3260,
PID 0x4011,
PID 0x4012

can.fuel.pressure

number

kPa

Fuel pressure read from CAN

PID 0x005E,
PID 0x210A

can.fuel.rate

number

g/s

Fuel rate read from CAN

PID 0x219D

can.fuel.system.state

number

Fuel system status read from CAN, bits 0 - open loop, 1 - closed loop, 2 - open loop drive, 3 - open loop fault, 4 - closed loop fault

PID 0x2103

can.fuel.temperature

number

celsius

Fuel temperature read from CAN

PID 0x00AE

can.fuel.type.enum

number

Fuel type read from CAN

PID 0x2151

can.gear

number

Current gear read from CAN. Numeric negative values are reverse gears, positive values are forward gears, zero is neutral

PID 0x21A4

can.gear.ratio

number

Transmission actual gear ratio read from CAN

PID 0x21A4

can.handbrake.status

boolean

CAN handbrake is pulled up

Protocol ID 0xB007

can.hood.status

boolean

CAN hood is opened

Protocol ID 0xB007

can.hybrid.battery.pack.life

number

percentage

Hybrid battery pack remaining life

PID 0x215B

can.intake.air.temperature

number

celsius

Intake air temperature

PID 0x0069,
PID 0x210F,
PID 0x2168

can.intake.map

number

kPa

Intake manifold absolute pressure

PID 0x0066,
PID 0x210B,
PID 0x2187

can.intercooler.temperature

number

celsius

Engine intercooler temperature read from CAN

PID 0x0034

can.long.fuel.trim

number

percentage

Short term fuel trim read from CAN

PID 0x2107,
PID 0x2109

can.maf.air.flow.rate

number

g/sec

MAF air flow rate read from CAN

PID 0x0084,
PID 0x2110

can.maf.max.air.flow.rate

number

g/sec

Maximum value for air flow rate from mass air flow sensor, read from CAN

PID 0x2150

can.mil.mileage

number

Distance traveled while malfunction indicator lamp is activated, read from CAN

PID 0x2121

can.mil.status

boolean

Malfunction indicator lamp status read from CAN

Protocol ID 0x4007 with Alarm Type 0x18

can.mil.time

number

hours

Time run with malfunction indicator lamp activated, read from CAN

PID 0x214D

can.monitor.status

number

Monitor status this drive cycle read from CAN, bitmask

PID 0x2141

can.oxygen.sensor.bitmask

number

Oxygen sensor bitmask read from CAN

PID 0x211D

can.oxygen.sensor.current

number

Oxygen sensor current read from CAN

PID 0x2134,
PID 0x2135,
PID 0x2136,
PID 0x2137,
PID 0x2138,
PID 0x2139,
PID 0x213A,
PID 0x213B

can.oxygen.sensor.fuel.air.ratio

number

Fuel-air equivalence ratio for the corresponding oxygen sensor read from CAN

PID 0x2124,
PID 0x2125,
PID 0x2126,
PID 0x2127,
PID 0x2128,
PID 0x2129,
PID 0x212A,
PID 0x212B,
PID 0x2134,
PID 0x2135,
PID 0x2136,
PID 0x2137,
PID 0x2138,
PID 0x2139,
PID 0x213A,
PID 0x213B

can.oxygen.sensor.fuel.trim

number

percentage

Short term fuel trim associated with current oxygen sensor

PID 0x2114,
PID 0x2115,
PID 0x2116,
PID 0x2117,
PID 0x2118,
PID 0x2119,
PID 0x211A,
PID 0x211B

can.oxygen.sensor.max.current

number

Maximum value for Oxygen sensor current

PID 0x214F

can.oxygen.sensor.max.fuel.air.ratio

number

Maximum value for the equivalence ratio of Oxygen sensor

PID 0x214F

can.oxygen.sensor.max.pressure

number

kPa

Maximum value for intake manifold absolute pressure

PID 0x214F

can.oxygen.sensor.max.voltage

number

volts

Maximum value for Oxygen sensor voltage

PID 0x214F

can.oxygen.sensor.output.voltage

number

volts

Oxygen sensor output voltage read from CAN

PID 0x2114,
PID 0x2115,
PID 0x2116,
PID 0x2117,
PID 0x2118,
PID 0x2119,
PID 0x211A,
PID 0x211B

can.oxygen.sensors.state

number

Location of oxygen sensors, bits 0 - sensor 1, 1 - sensor 2, 2 - sensor 3 etc. Bank1 sensors 1,2, bank 2 sensors 3,4 etc.

PID 0x2113

can.oxygen.sensor.voltage

number

volts

Voltage of the corresponding oxygen sensor read from CAN

PID 0x2124,
PID 0x2125,
PID 0x2126,
PID 0x2127,
PID 0x2128,
PID 0x2129,
PID 0x212A,
PID 0x212B

can.pedal.brake.status

boolean

CAN brake pedal pressed

Protocol ID 0xB007

can.pto.run.time

number

Power Take-Off run time read from CAN

PID 0x217F

can.pto.status

boolean

Power take-off status, read from CAN

PID 0x211E

can.rear.left.door.status

boolean

CAN rear left door is opened

Protocol ID 0xB007

can.rear.right.door.status

boolean

CAN rear right door is opened

Protocol ID 0xB007

can.relative.accelerator.pedal.position

number

percentage

Relative accelerator pedal position read from CAN

PID 0x215A

can.relative.fuel.rail.pressure

number

kPa

Fuel rail pressure relative to manifold vacuum

PID 0x2122

can.relative.throttle.position

number

percentage

Relative throttle position read from CAN

PID 0x2145

can.secondary.air.state

number

Commanded secondary air status read from CAN

PID 0x2112

can.secondary.long.fuel.trim

number

percentage

Long term secondary oxygen sensor fuel trim, index - the number of bank

PID 0x2156,
PID 0x2158

can.secondary.short.fuel.trim

number

percentage

Short term secondary oxygen sensor fuel trim, index - the number of bank

PID 0x2155,
PID 0x2157

can.service.mileage

number

Service distance read from CAN

PID 0x0392

can.short.fuel.trim

number

percentage

Short term fuel trim read from CAN

PID 0x2106,
PID 0x2108

can.throttle.actuator

number

percentage

Commanded throttle actuator position read from CAN

PID 0x214C

can.throttle.pedal.level

number

percentage

Throttle pedal push level read from CAN

PID 0x005B

can.throttle.position

number

percentage

Absolute throttle position for corresponding throttle position sensor read from CAN

PID 0x2111,
PID 0x2147,
PID 0x2148

can.timing.advance

number

degrees

Ignition timing advance read from CAN

PID 0x210E

can.total.engine.idle.time

number

hours

Time of engine running in idling status (vehicle stopped) since vehicle manufacture, read from CAN

PID 0x217F

can.transmission.input.speed

number

rpm

Transmittion input speed read from CAN

PID 0x00A1

can.transmission.oil.temperature

number

celsius

Transmission oil temperature read from CAN

PID 0x00B1

can.trip.fuel.consumed

number

liters

Volume of liquid fuel consumed for current trip read from CAN

PID 0x00B6,
PID 0x03E9,
PID 0x1B60,
PID 0x3043

can.turbo.oil.temperature

number

celsius

Turbocharger oil temperature read from CAN

PID 0x00B0

can.vehicle.mileage

number

Total vehicle mileage read from CAN

PID 0x00F5,
PID 0x21A6

can.vehicle.remaining.range

number

Vehicle Range read, from CAN

PID 0x4020

can.vehicle.speed

number

km/h

Vehicle speed read from CAN

PID 0x0054,
PID 0x210D

can.water.depth

number

meters

Water depth read from CAN

PID 0x4030

can.water.temperature

number

celsius

Water temperature read from CAN

PID 0x4050

can.wind.direction

number

rad

Wind direction read from CAN

PID 0x4040

can.wind.speed

number

m/s

Wind speed read from CAN

PID 0x4041

channel.id

number

ID of channel that received a message

crash.direction.enum

number

Crash direction - front, rear, left, right etc.

Protocol ID 0x4007 with Alarm Type 0x11

crash.event

boolean

Crash event detected

Protocol ID 0x4007 with Alarm Type 0x11

current.fuel.consumed

number

liters

Total fuel consumption from the latest ACC ON time to current time

Protocol ID 0x1001,
Protocol ID 0x1002,
Protocol ID 0x4001,
Protocol ID 0x4002,
Protocol ID 0x4003,
Protocol ID 0x4004,
Protocol ID 0x4005,
Protocol ID 0x4006,
Protocol ID 0x4007,
Protocol ID 0x4008,
Protocol ID 0x400B,
Protocol ID 0x400C,
Protocol ID 0x400D

current.trip.mileage

number

Mileage from the latest ACC ON time to current time

dangerous.driving.event

boolean

Dangerous driving event

Protocol ID 0x4007 with Alarm Type 0x1B

device.id

number

ID of device that received a message

device.name

string

Name of device that received a message

device.type.id

number

ID of device type of device that received a message

engine.blocked.status

boolean

Engine blocked status (fuel cutoff relay), true - engine is blocked, false - engine isn't blocked

Protocol ID 0xB007

engine.ignition.status

boolean

Engine ignition or ACC status

Protocol ID 0x4007 with Alarm Type 0x16,
Protocol ID 0x4007 with Alarm Type 0x17,
Protocol ID 0xB007

engine.temperature.high.status

boolean

High engine coolant temperature

Protocol ID 0x4007 with Alarm Type 0x03

event.enum

number

Protocol-specific event code

Protocol ID 0x4007

exhaust.emission.status

boolean

Exhaust emission

Protocol ID 0x4007 with Alarm Type 0x0A

fatigue.driving.status

boolean

Fatigue driving

Protocol ID 0x4007 with Alarm Type 0x0D

firmware.update.code

number

Firmware update confirmation code

Protocol ID 0xD005

firmware.update.type

number

Firmware update type: 0 - terminal， 80 - OBD module， 81 - Bluetooth module

Protocol ID 0xD005

geofence.id

number

Geofence ID

Protocol ID 0x4007 with Alarm Type 0x0F

geofence.status

boolean

Geofence entered status

Protocol ID 0x4007 with Alarm Type 0x0F

gnss.status

boolean

GNSS receiver on/off status

gsm.cellid

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) base station ID

Protocol ID 0x4008

gsm.lac

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) location area code

Protocol ID 0x4008

gsm.sim.iccid

string

Integrated Circuit Card Id of SIM card of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...)

Protocol ID 0xA002

gsm.sim.imsi

string

IMSI of SIM card of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...)

Protocol ID 0xA002

hardware.version

string

Hardware version

Protocol ID 0x1001

harsh.acceleration.event

boolean

Harsh acceleration detected

Protocol ID 0x4007 with Alarm Type 0x04

harsh.braking.event

boolean

Harsh braking detected

Protocol ID 0x4007 with Alarm Type 0x05

harsh.cornering.event

boolean

Harsh cornering detected

Protocol ID 0x4007 with Alarm Type 0x0C

headlight.status

boolean

Headlights status

Protocol ID 0xB007

high.rpm.status

boolean

High engine RPM

Protocol ID 0x4007 with Alarm Type 0x08

ibutton.code

string

Hexadecimal code of connected iButton

Protocol ID 0x400C

ident

string

Device unique identifier like serial number, IMEI, etc

idle.status

boolean

Vehicle is in idling state

Protocol ID 0x4007 with Alarm Type 0x06

ignition.on.timestamp

number

seconds

The latest ACC ON timestamp

illegal.enter.event

boolean

Illegal enter

Protocol ID 0x4007 with Alarm Type 0x13

illegal.ignition.event

boolean

Illegal ignition

Protocol ID 0x4007 with Alarm Type 0x14

message.buffered.status

boolean

Black box message

Protocol ID 0x4001

no.card.event

boolean

No card presented

Protocol ID 0x4007 with Alarm Type 0x1A

obd.error.event

boolean

OBD communication error

Protocol ID 0x4007 with Alarm Type 0x15

obd.standard.enum

number

OBD standards this vehicle conforms to

PID 0x211C

overspeeding.event

boolean

Overspeeding detected

overspeeding.status

boolean

Overspeeding detected

Protocol ID 0x4007 with Alarm Type 0x01

peer

string

IP:port from which device connecting to the channel

position.direction

number

degrees

Heading angle at position detection moment

Protocol ID 0x4009

position.fix.type

number

GNSS fix type enum (0 = "not fixed", 1 = "2D", 2 = "3D", null = "unknown")

Protocol ID 0x4009

position.latitude

number

degrees

Latitude coordinate value

Protocol ID 0x4009

position.longitude

number

degrees

Longitude coordinate value

Protocol ID 0x4009

position.satellites

number

Quantity of satellites used to calculate coordinates for given position information

Protocol ID 0x4009

position.speed

number

km/h

Instant speed at position detection moment

Protocol ID 0x4009

position.timestamp

number

seconds

Timestamp when coordinates where calculated

Protocol ID 0x4009

power.on.status

boolean

Power-on device status

Protocol ID 0x4007 with Alarm Type 0x09,
Protocol ID 0x4007 with Alarm Type 0x0E

private.status

boolean

Device is in private mode

protocol.id

number

ID of protocol

quick.lane.change.event

boolean

Quick lane change status

Protocol ID 0x4007 with Alarm Type 0x0B

rfid.code

string

Hexadecimal code of connected RFID

Protocol ID 0x400D

sample.rate

number

seconds

Sample rate of accelerometer data

Protocol ID 0x4003

server.timestamp

number

seconds

Timestamp when server received a message

software.version

string

Software version string

Protocol ID 0x1001

tamper.alarm

boolean

Tamper alarm event

Protocol ID 0x4007 with Alarm Type 0x12

timestamp

number

seconds

Message timestamp

total.fuel.consumed

number

liters

Total fuel consumption from device power on to the latest ACC ON time

total.trip.mileage

number

The accumulated mileage from device power on to the latest ACC ON time

towing.event

boolean

Towing event detected

Protocol ID 0x4007 with Alarm Type 0x07

trip.mileage

number

Distance driven since engine start

PID 0x00F4

turn.left.status

boolean

Turn left status

Protocol ID 0xB007

turn.right.status

boolean

Turn right status

Protocol ID 0xB007

unlock.event

boolean

Unlock event

Protocol ID 0x4007 with Alarm Type 0x19

vehicle.vin

string

VIN of vehicle

Protocol ID 0xA002

vibration.alarm

boolean

Vibration alarm event

Protocol ID 0x4007 with Alarm Type 0x1C

voltage.low.status

boolean

Low voltage

Protocol ID 0x4007 with Alarm Type 0x02

Title

Name

Description

Properties

Report settings

report

time: Report by time

model: GPS location model

groups: Groups of GPS data

heading: Report by heading change

distance: Report by distance

Title

Name

Description

Properties

Custom command Examples

custom

Send custom command to device

payload: Payload HEX string

Query Towing alarm (0x1007) parameter

{"payload":"20020001011007"}

Get configuration parameter Examples

getparam

Query setting of mobile terminal

param: Tag number

Get GPS sample rate by time interval

{"param":"1102"}

Sinocastel IDD-213W

Here’s the like of JSON you get

How to consume this nice JSON

How to send commands to Sinocastel IDD-213W?

You can also

Modify messages

Aggregate data

More devices from Sinocastel (8)
