SPOT Gen3
Flespi parses telemetry data from your SPOT Gen3 into a standardized JSON and
lets you send commands to SPOT Gen3 via API.
Here’s the like of JSON you get
{
"ident": "352625333222111",
"position.altitude": 273.61,
"position.hdop": 0.7,
"position.latitude": 49.069782,
"position.longitude": 28.632826,
"position.satellites": 18,
"server.timestamp": 1650636570.426424,
"timestamp": 1650636570.426424,
"device.type.id": "SPOT Gen3",
"channel.id": 1111,
"protocol.id": "spot-receiver"
"engine.ignition.status": true
...
}
How to consume this nice JSON
The easiest way is to make a REST API request like this
curl -X GET --header 'Authorization: FlespiToken XXX' 'https://flespi.io/gw/devices/<device id>/messages'
You can also
Modify messages
Add or remove parameters, inject data from LBS and reverse-geocoding services, etc.
Learn what plugins can do
Aggregate data
Determine trips and stops, catch events, detect geofence ins/outs, and more.
Learn about flespi analytics capabilities battery.state
string
Battery state
batteryState
channel.id
number
ID of channel that received a message
custom
number
Any custom parameter
device.id
number
ID of device that received a message
device.name
string
Name of device that received a message
device.self.name
string
Device name reported by the device
esnName
device.type.id
number
ID of device type of device that received a message
ident
string
Device unique identifier like serial number, IMEI, etc
esn
message.detail
string
Message detail
messageDetail
message.type
string
Message type
messageType
peer
string
IP:port from which device connecting to the channel
position.latitude
number
degrees
Latitude coordinate value
latitude
position.longitude
number
degrees
Longitude coordinate value
longitude
protocol.id
number
ID of protocol
server.timestamp
number
seconds
Timestamp when server received a message
streaming.mode
string
A field that tells the mode of operation. TEST for data pushed as a part of a test operation or test request, LIVE for data from Production / Live system and RECOVERY for data pushed due to a data recovery request.
timestamp
number
seconds
Message timestamp
timeInGMTSecond
