Protocol used by GPS tracking devices manufactured by Skypatrol headquartered in the USA.
flespi parses the Skypatrol protocol messages into a JSON object with the
fields listed below in the Parameters tab.
To connect your tracker using the Skypatrol protocol, you need to have a skypatrol channel created first.
Point your tracker to the channel's domain name:port via SMS or configuration tool provided by the vendor.
Then create a device instance for your tracker and use a 15-character IMEI (usually specified on the tracker casing) in the ident field.
Use the Toolbox tab on the device screen to check if the messages are coming.
There are two separate variations of the protocol and one should be correctly selected in the channel configuration under 'Protocol version' setting:
- '5-byte header' — for Skypatrol TT8750+ devices and analogs (more modern version, try it first)
- '4-byte header' — for Skypatrol TT8750 devices and analogs (older version, enfora types of devices)
For Skypatrol devices to work correctly via skypatrol channel, they should be configured as follows:
'5-byte header' devices:
Keep-alive message mask must be = 7:
- bits enabled:
- bit0 — binary format
- bit1 — add param1 to keep-alive message
- bit2 — add device ID to the keep-alive message
- bits disabled:
- bit27 — do not add a mask to keep-alive message
- bit28 — do not add sequence number to keep-alive message
Position message mask must have bit27 enabled — add report mask to position messages.
'4-byte header' devices Output Event 52 Parm2 bit field:
- bits enabled:
- bit1 — Parm1
- bit2 — modem ID
- bit3 — IO data
- bit7 — event category
- bit12 — GPS data
- bit20 — odometer
- bits disabled:
- bit0 — ASCII format
- all other
ain
number
volts
Voltage on the analog input
battery.level
number
percentage
Internal battery level
battery.voltage
number
volts
Internal battery voltage
channel.id
number
ID of channel that received a message
counter.limit
number
Counter limit
counter.type
number
Counter type
counter.value
number
Current value of counter
device.id
number
ID of device that received a message
device.name
string
Name of device that received a message
device.type.id
number
ID of device type of device that received a message
din
number
Digital inputs bitmask
dout
number
Digital outputs bitmask
engine.ignition.status
boolean
Engine ignition or ACC status
event.enum
number
Protocol-specific event code
geofence.group
number
Last triggered geofence group number
geofence.index
number
Last triggered geofence index inside group
gps.led.status
boolean
GPS LED status: truee - on, false - off
gsm.arfcn
number
Absolute radio-frequency channel number of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...)
gsm.cellid
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) base station ID
gsm.lac
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) location area code
gsm.led.status
boolean
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) LED status: truee - on, false - off
gsm.mcc
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) country code
gsm.mnc
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) code
gsm.signal.dbm
number
dbm
Strength of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal
gsm.timing.advance
number
Mobile network (GSM, 3G, 4G, LTE, 5G, ...) timing advance
ident
string
Device unique identifier like serial number, IMEI, etc
magnetic.variation
number
degrees
Magnetic variation
main.power.status
boolean
Main power state
message.seqnum
number
Sequence number of the message
overspeeding.duration
number
seconds
Overspeeding interval duration
overspeeding.max.speed
number
km/h
Maximum speed during overspeeding interval
peer
string
IP:port from which device connecting to the channel
position.altitude
number
meters
Altitude value for position
position.direction
number
degrees
Heading angle at position detection moment
position.latitude
number
degrees
Latitude coordinate value
position.longitude
number
degrees
Longitude coordinate value
position.satellites
number
Quantity of satellites used to calculate coordinates for given position information
position.speed
number
km/h
Instant speed at position detection moment
position.timestamp
number
seconds
Timestamp when coordinates where calculated
position.valid
boolean
Is position information accurate and valid for given timestamp
protocol.id
number
ID of protocol
server.timestamp
number
seconds
Timestamp when server received a message
timestamp
number
seconds
Message timestamp
trip.mileage
number
km
Distance driven since engine start
vehicle.mileage
number
km
Total calculated mileage
