Ruptela FM-Pro4

Ruptela FM-Pro4 is a GPS tracking device for heavy vehicles. This device is designed for standard vehicle tracking and monitoring tasks and can obtain information from standard CANbus protocols such as FMS and J1708. The device communicates using GSM (2G) networks, and it is also available in version that supports UMTS (3G).

Protocol: ruptela Manufacturer: Ruptela Forum discussion
Properties
Coefficients
coefficients1
radial: Radial
distance: Distance
time_with_engine: Time with engine
Coefficients
coefficients2
radial: Radial
distance: Distance
time_with_engine: Time with engine
Coefficients
coefficients3
radial: Radial
distance: Distance
time_with_engine: Time with engine
Coefficients
coefficients4
radial: Radial
distance: Distance
time_with_engine: Time with engine
Connection data
connection
Connection data
apn: APN
server: Server
protocol: Protocol
secondary_server: Secondary server
Constant link, keep alive and heartbeat
constant_link1
heartbeat: Enable heartbeat
keepalive: Enable keep alive mode
const_link: Enable constant link mode
Constant link, keep alive and heartbeat
constant_link2
heartbeat: Enable heartbeat
keepalive: Enable keep alive mode
const_link: Enable constant link mode
Constant link, keep alive and heartbeat
constant_link3
heartbeat: Enable heartbeat
keepalive: Enable keep alive mode
const_link: Enable constant link mode
Constant link, keep alive and heartbeat
constant_link4
heartbeat: Enable heartbeat
keepalive: Enable keep alive mode
const_link: Enable constant link mode
Get GPS
coords
Get current GPS status and coordinates
Data collection
data_collection1
enable: Enable
engine: Egine
logging_interval: SD card logging interval
time_without_engine: Time without engine
Data collection
data_collection2
enable: Enable
engine: Egine
logging_interval: SD card logging interval
time_without_engine: Time without engine
Data collection
data_collection3
enable: Enable
engine: Egine
logging_interval: SD card logging interval
time_without_engine: Time without engine
Data collection
data_collection4
enable: Enable
engine: Egine
logging_interval: SD card logging interval
time_without_engine: Time without engine
Data sending
data_sending1
enable: Enable
period: Period
min_records: Min records
link_timeout: Link timeout
Data sending
data_sending2
enable: Enable
period: Period
min_records: Min records
link_timeout: Link timeout
Data sending
data_sending3
enable: Enable
period: Period
min_records: Min records
link_timeout: Link timeout
Data sending
data_sending4
enable: Enable
period: Period
min_records: Min records
link_timeout: Link timeout
Device Information
device_info_fm4
Device Information
imsi: IMSI
fw_ver: Firmware Version
hw_ver: Hardware Version
cfg_tag: CFG tag
boot_ver: Bootloader Version
dev_type: Device Type
angl_coef: Angle Coefficient
dist_coef: Distance Coefficient
time_coef: Time Coefficient
ocsp_status: OCSP Status
gsm_operator: GSM Operator
Reset the state of activated DOUTs
doutreset
ECO-drive: Harsh acceleration limit
eco_acceleration
limit: Harsh acceleration limit
ECO-drive: Braking limit
eco_braking
harsh_limit: Harsh braking limit
extreme_limit: Extreme braking limit
ECO-drive: Cornering limit
eco_cornering
limit: Cornering limit
Eco-drive: Idling
eco_idling
idling_delay: Idling delay
idling_speed: Idling speed
Force device to connect to server for one time
econnect
Force device to connect (for one time) to server with custom APN, user, pass, IP, port and protocol settings. Device creates dummy record just with header part. Triggered event ID = 0.
ip: IP Address
port: Port
apn_name: APN Name
protocol: Protocol
apn_login: APN Login
apn_password: APN Password
ECO-drive: Overspeeding limit
eco_overspeeding
limit: Overspeeding limit
Device Identification
identification
Device Identification information provided on every device connection
imsi: IMSI
angl_coef: Angle Coefficient
dist_coef: Distance Coefficient
time_coef: Time Coefficient
device_type: Device Type
gsm_operator: GSM Operator
firmware_version: Firmware Version
Immobilize the vehicle
immobilizer
speed: Speed
Set odometer value
odometer
Used by server to set specific value of device's virtual odometer
value: Odometer value
Reset Device
reset
Reset (reboot) the device
Reset imoobilizer functionality
resetimmob
Setio
setio2
Set Dout1 and Dout2 output level.
dout1: Dout 1
dout2: Dout 2
Setiotime
setiotime2
Set Dout1 and Dout2 output level for temporary period.
dout1: Dout 1
dout2: Dout 2
Snapshot
snapshot
Take picture on demand via connected peripherals with cameras
peripheral: Peripheral
Properties
Custom Command
custom
Send command over GPRS
hex: Command payload is encoded as HEX string
payload: Command payload
command_id: Command ID
Send Data to Germin Device
{"hex":true,"payload":"64617461","command_id":131}
Get Status of Garmin Device
{"payload":"","command_id":130}
Request Diagnostic Trouble Codes from Device
{"hex":true,"payload":"02","command_id":109}
Set output 1 to OFF, output 2 leave unchanged, and output 3 to ON
{"payload":"setio 0,2,1","command_id":108}
