WanWay GS05

WanWay GS05 is a smart 3G GPS tracking device with GSM and GPS technology, designed for vehicles. Features include real-time tracking, SOS emergency call, remotely cut-off petrol/electricity, and supports multiple function ports. The device offers geo-fence and over-speed alarms, trace playback, and mileage reports.

Protocol: wanway Manufacturer: Shanghai WanWay Digital Technology Co., Ltd.

Usage specifics

Parameters (47)

Commands (1)

AI Assistant

Here’s the like of JSON you get

{
    "ident": "352625333222111",
    "position.altitude": 273.61,
    "position.hdop": 0.7,
    "position.latitude": 49.069782,
    "position.longitude": 28.632826,
    "position.satellites": 18,
    "server.timestamp": 1650636570.426424,
    "timestamp": 1650636570.426424,
    "device.type.id": "WanWay GS05",
    "channel.id": 1111,
    "protocol.id": "wanway"
    "engine.ignition.status": true
    ...
}

How to consume this nice JSON

The easiest way is to make a REST API request like this

curl -X GET  --header 'Authorization: FlespiToken XXX' 'https://flespi.io/gw/devices/<device id>/messages'

Explore REST API Show more ways to consume data How to connect my WanWay GS05 to flespi

How to send commands to WanWay GS05?

You can send a specific command. Show all commands

You can also

Modify messages

Add or remove parameters, inject data from LBS and reverse-geocoding services, etc.

Learn what plugins can do

Aggregate data

Determine trips and stops, catch events, detect geofence ins/outs, and more.

Learn about flespi analytics capabilities

Name

Type

Unit

Description

Sources

battery.charging.status

boolean

Battery charging status

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

battery.level

number

percentage

Internal battery level

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

battery.low.alarm

boolean

Battery low alarm event

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

channel.id

number

ID of channel that received a message

defense.active.status

boolean

Defense activated status

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

device.id

number

ID of device that received a message

device.imei

string

IMEI of the device

Protocol Number 0x94 with Information Type 0x0A

device.name

string

Name of device that received a message

device.type.id

number

ID of device type of device that received a message

engine.blocked.status

boolean

Engine blocked status (fuel cutoff relay), true - engine is blocked, false - engine isn't blocked

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

engine.ignition.status

boolean

Engine ignition or ACC status

Protocol Number 0x12,
Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x26

external.powersource.voltage

number

volts

External power voltage

Protocol Number 0x94 with Information Type 0x00

geofence.status

boolean

Geofence entered status

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

gnss.realtime.status

boolean

True - GNSS realtime positioning, False - differential positioning

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x26

gnss.status

boolean

GNSS receiver on/off status

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

gsm.cellid

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) base station ID

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26

gsm.lac

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) location area code

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26

gsm.mcc

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) country code

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26

gsm.mnc

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) code

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26

gsm.signal.dbm

number

dbm

Strength of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal

Protocol Number 0x24

gsm.signal.level

number

percentage

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal strength level

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

gsm.sim.iccid

string

Integrated Circuit Card Id of SIM card of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...)

Protocol Number 0x94 with Information Type 0x0A

gsm.sim.imsi

string

IMSI of SIM card of the Mobile network (GSM, 3G, 4G, LTE, 5G, ...)

Protocol Number 0x94 with Information Type 0x0A

gsm.timing.advance

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) timing advance

Protocol Number 0x24

harsh.acceleration.event

boolean

Harsh acceleration detected

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

harsh.braking.event

boolean

Harsh braking detected

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

harsh.cornering.event

boolean

Harsh cornering detected

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

ident

string

Device unique identifier like serial number, IMEI, etc

language

string

Language used on the device

Protocol Number 0x13,
Protocol Number 0x15,
Protocol Number 0x16,
Protocol Number 0x26

message.buffered.status

boolean

Black box message

Protocol Number 0x22

overspeeding.event

boolean

Overspeeding detected

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

peer

string

IP:port from which device connecting to the channel

position.direction

number

degrees

Heading angle at position detection moment

position.latitude

number

degrees

Latitude coordinate value

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x26

position.longitude

number

degrees

Longitude coordinate value

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x26

position.satellites

number

Quantity of satellites used to calculate coordinates for given position information

position.speed

number

km/h

Instant speed at position detection moment

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x26

position.valid

boolean

Is position information accurate and valid for given timestamp

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x26

power.cut.alarm

boolean

External power cut-off alarm event

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

protocol.id

number

ID of protocol

protocol.number

number

Protocol number

rfid.code

string

Hexadecimal code of connected RFID

Protocol Number 0x94 with Information Type 0x1B

server.timestamp

number

seconds

Timestamp when server received a message

sos.alarm

boolean

SOS alarm triggerred

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

timestamp

number

seconds

Message timestamp

Protocol Number 0x12,
Protocol Number 0x16,
Protocol Number 0x22,
Protocol Number 0x24,
Protocol Number 0x26

vehicle.mileage

number

Total calculated mileage

Protocol Number 0x12,
Protocol Number 0x22

vibration.alarm

boolean

Vibration alarm event

Protocol Number 0x13,
Protocol Number 0x16,
Protocol Number 0x26

Title

Name

Description

Properties

Custom Command for and MV22, MV208 device types Examples

custom

Send custom command to devices of type MV22, MV208

payload: SMS/GPRS command Payload

Cutting Oil and Electricity

{"payload":"RELAY,1#"}

Connecting Oil and Electricity

{"payload":"RELAY,0#"}
