Teltonika FMB630

Teltonika FMB630 is a leading GLONASS/GPS tracker with dual-SIM, Bluetooth connectivity, remote configuration, microSD card, integrated tachograph solution, RS232/RS485 functionality, and much more.

Protocol: teltonika Manufacturer: Teltonika Forum discussion
Properties
SIM1 APN Password
apn_password_sim1
GPRS APN Password for SIM1.
password: APN Password
SIM2 APN Password
apn_password_sim2
GPRS APN Password for SIM2.
password: APN Password
SIM1 APN Name
apn_sim1
GPRS APN Name for SIM1.
apn: APN Name
SIM2 APN Name
apn_sim2
GPRS APN Name for SIM2.
apn: APN Name
SIM1 APN Username
apn_username_sim1
GPRS APN Username for SIM1.
username: APN Username
SIM2 APN Username
apn_username_sim2
GPRS APN Username for SIM2.
username: APN Username
Digital Outputs
outputs
Change state of digital outputs 1 - 4
out1: Output 1
out2: Output 2
out3: Output 3
out4: Output 4
Profile 1: Backend Server 1
server1_profile1
Profile 1: Backend Server 1 Settings
host: Backend server 1 host
mode: Backend server 1 protocol
port: Backend server 1 port
enable: Enable GPRS context for server 1
timeout: Backend server 1 response timeout
Profile 2: Backend Server 1
server1_profile2
Profile 2: Backend Server 1 Settings
host: Backend server 1 host
mode: Backend server 1 protocol
port: Backend server 1 port
enable: Enable GPRS context for server 1
timeout: Backend server 1 response timeout
Profile 3: Backend Server 1
server1_profile3
Profile 3: Backend Server 1 Settings
host: Backend server 1 host
mode: Backend server 1 protocol
port: Backend server 1 port
enable: Enable GPRS context for server 1
timeout: Backend server 1 response timeout
Profile 4: Backend Server 1
server1_profile4
Profile 4: Backend Server 1 Settings
host: Backend server 1 host
mode: Backend server 1 protocol
port: Backend server 1 port
enable: Enable GPRS context for server 1
timeout: Backend server 1 response timeout
Profile 1: Backend Server 2
server2_profile1
Profile 1: Backend Server 2 Settings
host: Backend server 2 host
mode: Backend server 2 protocol
port: Backend server 2 port
enable: Enable GPRS context for server 2
timeout: Backend server 2 response timeout
Profile 2: Backend Server 2
server2_profile2
Profile 2: Backend Server 2 Settings
host: Backend server 2 host
mode: Backend server 2 protocol
port: Backend server 2 port
enable: Enable GPRS context for server 2
timeout: Backend server 2 response timeout
Profile 3: Backend Server 2
server2_profile3
Profile 3: Backend Server 2 Settings
host: Backend server 2 host
mode: Backend server 2 protocol
port: Backend server 2 port
enable: Enable GPRS context for server 2
timeout: Backend server 2 response timeout
Profile 4: Backend Server 2
server2_profile4
Profile 4: Backend Server 2 Settings
host: Backend server 2 host
mode: Backend server 2 protocol
port: Backend server 2 port
enable: Enable GPRS context for server 2
timeout: Backend server 2 response timeout
Action command setdigout
setdigout_4
Send setdigout command to control digital outputs 1 - 4 with timeout and speed limit options
out1: State of digital output 1
out2: State of digital output 2
out3: State of digital output 3
out4: State of digital output 4
Properties
Codec 12 command
codec12
Send command encoded in Codec 12
hex: Payload is encoded as HEX string
crlf: Add CR and LF bytes after text payload
payload: Text or hex data to send
wait_response: Wait Response
Set output 3 to ON for 5 seconds, and set outputs 1,2,4 to OFF
{"payload":"setdigout 0010 0 0 5 0"}
Custom command
custom
Send custom command via connection or over SMS
Force device to generate a record and connect to server to deliver it
{"text":"getrecord"}
Send custom bytes to device as codec 12 command. May be used to communicate with external equipment connected over serial port
{"hex":"DEADBEEF"}
Get configuration param
getparam
Get configuration parameter by its number
param: Param number
Set configuration param
setparam
Set configuration parameter by its number
param: Param number
value: Param value
