The protocol for Neomatica GPS tracking devices.
Below is the list of parameters that can appear in the messages received by the channel via neomatica protocol. In most parameters, the name consists of tags split by dots: tag1.tag2.tag3.tag4... Each tag defines a certain area of an application, e.g. any parameter that contains mileage data has the 'mileage' tag in the name and any parameter related to fuel control contains the 'fuel' tag. By default JSON fields of the message received by a channel via this protocol can only contain the below-specified parameters. Any additional parameter will be prefixed by the "custom" tag, e.g. "custom.unspecified-name".
Name | Type | Unit | Description |
absolute.acceleration | number | g | Module of accelerometer vector |
ain | number | volts | Voltage on the analog input |
alarm.event | boolean | Alarm event triggered | |
alarm.mode.status | boolean | Device alarm mode status | |
battery.low.alarm | boolean | Battery low alarm event | |
battery.voltage | number | volts | Internal battery voltage |
can.tag.number | number | User defined can tag number | |
can.tag.value | number | Can tag value, merge by parameter index | |
case.status | boolean | Case opened status | |
channel.id | number | ID of channel that received a message | |
counter.impulses | number | Impulses counter | |
device.id | number | ID of device that received a message | |
device.model | string | Device model ID string | |
device.name | string | Name of device that received a message | |
device.type.id | number | ID of device type of device that received a message | |
din | number | Digital inputs bitmask | |
dout | number | Digital outputs bitmask | |
event.enum | number | Event code, full list of codes available at separate table | |
external.powersource.status | boolean | External power source connection status | |
external.powersource.voltage | number | volts | External power voltage |
fuel.level | number | percentage | Fuel level percentage |
glonass.position.satellites | number | Quantity of satellites from GLONASS used to calculate coordinates for given position information | |
gnss.vehicle.mileage | number | km | Vehicle mileage calculated by global navigation system (GNSS) |
gps.position.satellites | number | Quantity of satellites from GPS used to calculate coordinates for given position information | |
gsm.sim.status | boolean | SIM card is active | |
ident | string | Device unique identificator and optional password | |
movement.status | boolean | Current movement state | |
peer | string | IP:port from which device connecting to the channel | |
position.altitude | number | meters | Altitude value for position |
position.direction | number | degrees | Heading angle at position detection moment |
position.hdop | number | Horizontal dilution of precision | |
position.latitude | number | degrees | Latitude coordinate value |
position.longitude | number | degrees | Longitude coordinate value |
position.satellites | number | Quantity of satellites used to calculate coordinates for given position information | |
position.speed | number | km/h | Instant speed at position detection moment |
position.valid | boolean | Is position information accurate and valid for given timestamp | |
protocol.id | number | ID of protocol | |
sensor.temperature | number | celsius | Temperature sensor value |
server.timestamp | number | seconds | Timestamp when server received a message |
software.version | string | Software version string | |
timestamp | number | seconds | Message timestamp |
Below is the list of commands that can be sent to devices to change their configuration or to send signals to various outputs. When sending a command you can specify the transport type defining how the command will be delivered - the address parameter can take values connection (via network connection once the device goes online), sms (via SMS message), push (via PUSH notification). A comprehensive format of each command with all possible parameter values, parameter types, default values, etc. can be found in the REST API documentation in your flespi.io account.
Title | Name | Description | Properties |
Custom command | custom | Send custom command to device | parameters: Optional parameters command_name: Command name |
Reboot the device
{"command_name":"RESET"}
Set period of tracking to 30 seconds in motion and 300 seconds without motion
{"parameters":"30,300","command_name":"PERIOD"}
Compose report message from the main data only. Do not include additional data
{"parameters":"0","command_name":"PROTOCOL"}
|
