OMNI OT303BL

OMNI OT303BL is a new sharing scooter with LTE support. The device features anti-theft protection, built-in smart lock, GPS+GLONASS/GPS+BDS connectivity, IPX7 rating, 900mAh battery, and more.

Make your OMNI OT303BL devices a part of any infrastructure by connecting them via flespi telematics hub. Manage the device settings using flespi device management platform. Learn how to configure OMNI OT303BL with flespi.

Protocol: omni Manufacturer: Omni Change log: omni

Usage specifics

Parameters (54)

Settings (9)

Commands (1)

AI Assistant

Here’s the like of JSON you get

{
    "ident": "352625333222111",
    "position.altitude": 273.61,
    "position.hdop": 0.7,
    "position.latitude": 49.069782,
    "position.longitude": 28.632826,
    "position.satellites": 18,
    "server.timestamp": 1650636570.426424,
    "timestamp": 1650636570.426424,
    "device.type.id": "OMNI OT303BL",
    "channel.id": 1111,
    "protocol.id": "omni"
    "engine.ignition.status": true
    ...
}

How to consume this nice JSON

The easiest way is to make a REST API request like this

curl -X GET  --header 'Authorization: FlespiToken XXX' 'https://flespi.io/gw/devices/<device id>/messages'

Explore REST API Show more ways to consume data How to connect my OMNI OT303BL to flespi

How to send commands to OMNI OT303BL?

You can send a specific command. Show all commands

You can use pre-defined settings to send instructions more conveniently. Show all settings

You can also

Modify messages

Add or remove parameters, inject data from LBS and reverse-geocoding services, etc.

Learn what plugins can do

Aggregate data

Determine trips and stops, catch events, detect geofence ins/outs, and more.

Learn about flespi analytics capabilities

Name

Type

Unit

Description

Sources

battery.charging.status

boolean

Battery charging status

Instruction type H0,
Instruction type S6

battery.level

number

percentage

Internal battery level

Instruction type H0,
Instruction type Q0,
Instruction type S5,
Instruction type S6

battery.lock.status

boolean

Battery lock locked/unlocked status

Instruction type L6

battery.low.alarm

boolean

Battery low alarm event

Instruction type W0

battery.serial

string

Scooter battery serial number

Instruction type L6

battery.voltage

number

volts

Internal battery voltage

Instruction type H0,
Instruction type Q0,
Instruction type S5,
Instruction type S6

bms.serial.number

string

BMS (Battery Management System) serial number

Instruction type M1

channel.id

number

ID of channel that received a message

device.id

number

ID of device that received a message

device.name

string

Name of device that received a message

device.serial.number

string

Device serial number

Instruction type M1

device.type.id

number

ID of device type of device that received a message

disassemble.alarm.status

boolean

Illegal disassembling alarm event status

Instruction type W0

ecu.error.code

string

ECU error code

Instruction type E0,
Instruction type E1

error.type

number

Protocol-specific error identification number

Instruction type H0,
Instruction type S5,
Instruction type S6

error.type.description

string

Protocol-specific error error description string

Error type 1,
Error type 10,
Error type 11,
Error type 13,
Error type 3,
Error type 4,
Error type 6

event.enum

number

Protocol-specific event code

Instruction type S1,
Instruction type W0,
Instruction type W1

external.equipment.state

number

External equipment state

Instruction type L5

external.equipment.type

number

External equipment type

Instruction type L5

fall.alarm.status

boolean

Fall alarm status

Instruction type W0

gsm.mcc

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) country code

Instruction type Q0

gsm.mnc

number

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) code

Instruction type Q0

gsm.operator.code

string

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) operator code, which is MCC joined with MNC

Instruction type Q0

gsm.signal.level

number

percentage

Mobile network (GSM, 3G, 4G, LTE, 5G, ...) signal strength level

Instruction type H0,
Instruction type Q0,
Instruction type S5,
Instruction type S6

ident

string

Device unique identifier like serial number, IMEI, etc

illegal.movement.alarm

boolean

Illegal movement alarm event

Instruction type W0

indication.mode

string

Position indication mode: A - autonomous, D - differential, E - estimate, N - invalid data

Instruction type D0,
Instruction type D1

lock.status

boolean

Lock status

Instruction type H0,
Instruction type L0,
Instruction type L1,
Instruction type S5,
Instruction type S6

message.type

string

Message type

movement.event

boolean

Movement detected

Instruction type W0

payload.text

string

Text Payload received from device

Instruction type K0,
Instruction type U0,
Instruction type U1,
Instruction type U2,
Instruction type U3,
Instruction type Z0

peer

string

IP:port from which device connecting to the channel

position.altitude

number

meters

Altitude value for position

Instruction type D0,
Instruction type D1

position.hdop

number

Horizontal dilution of precision

Instruction type D0,
Instruction type D1

position.latitude

number

degrees

Latitude coordinate value

Instruction type D0,
Instruction type D1

position.longitude

number

degrees

Longitude coordinate value

Instruction type D0,
Instruction type D1

position.satellites

number

Quantity of satellites used to calculate coordinates for given position information

Instruction type D0,
Instruction type D1,
Instruction type S5

position.speed

number

km/h

Instant speed at position detection moment

Instruction type S6

position.valid

boolean

Is position information accurate and valid for given timestamp

Instruction type D0,
Instruction type D1

protocol.id

number

ID of protocol

reboot.event

boolean

Device reboot event

Instruction type Q38

remaining.range

number

Current remaining range

Instruction type S6

report.reason

number

Transmission reason code

Instruction type C0

rfid.card.type

string

RFID card type

Instruction type C0

rfid.code

string

Hexadecimal code of connected RFID

Instruction type C0

server.timestamp

number

seconds

Timestamp when server received a message

software.version

string

Software version string

Instruction type Q0,
Instruction type U0

speed.mode

number

Current mode of scooter 1:low speed 2:medium speed 3:high speed

Instruction type S6

timestamp

number

seconds

Message timestamp

Instruction type D0,
Instruction type D1,
Instruction type L0,
Instruction type L1,
Instruction type Q38

trip.duration

number

seconds

Trip duration

Instruction type L1

trip.mileage

number

Distance driven since engine start

Instruction type S6

unlock.timestamp

number

seconds

Bike unlock instruction received timestamp

Instruction type L1

vehicle.state

string

Vehicle state, such as moving, idling, parked etc

Instruction type S6

vendor.code

string

Vendor identification string code

Title

Name

Description

Properties

D0 Get positioning instructions, single time

D1 Positioning tracking commands

upload_interval: Upload positioning interval

R0 Unlocking/Lock operation request command

Send R0 command (timestamp appended automatically). After device response L0 or L1 command will be sent by server automatically.

lock: Lock/Unlock

user_id: User ID

key_time: Key effective time

S1 Event notification command

event_code: Event code

S4 Scooter setting instruction 2

Note: The following settings are saved after power down.

startup_mode: Startup mode setting

cruise_control: Cruise control setting

low_speed_limit: Low speed mode speed limit value

high_speed_limit: High speed mode speed limit value

inch_speed_display: Inch speed display

medium_speed_limit: Medium speed mode speed limit value

key_switch_headlight: Key switch headlight

button_switching_speed_mode: Button switching speed mode

S5 IoT device settings

Note: The following settings are saved after power down.

acc_sens: Accelerometer sensitivity

upload_s6: Status for upload scooter info (S6)

heartbeat_interval: Heartbeat upload interval

s6_upload_interval: Scooter information (S6) upload interval

S6 Obtain scooter information

Send S6 command: ask scooter for telemetry inforamtion.

S7 Scooter setting instruction 1

Note: The following setting information is not saved after power-off, and the default value is restored after restarting or unlocking.

mode: Mode setting

headlight_switch: Headlight switch

throttle_response: Throttle response

taillights_flashing: Taillights flashing

V0 Beep playback commands

play_content: Play content

Title

Name

Description

Properties

Custom command Examples

custom

Send custom command to device. Format for R0 and L0 commands : 0xFFFF*SCOS,OM,{ident},{instruction_type},{payload},# Format for other commands with payload: 0xFFFF*SCOS,OM,{ident},{instruction_type},{payload}# Format for commands with no payload: 0xFFFF*SCOS,OM,{ident},{instruction_type}# Note: The following settings are saved after power down.

payload: Comma separated list of parameters to send as payload

instruction_type: 2 letter instruction type

D0 - Get position instruction

{"instruction_type":"D0"}

I0 - Get the SIM card ICCID number

{"instruction_type":"I0"}

S6 - Obtain scooter information command

{"instruction_type":"S6"}

D1 Upload positioning interval 60 seconds

{"payload":"60","instruction_type":"D1"}

R0 Unlocking/Lock operation request command

{"payload":"0,20,1234","instruction_type":"R0"}

V0 Beep playback commands: 2: Find a scooter alert

{"payload":"2","instruction_type":"V0"}

L0 Unlocking command, e.g. 255 value received as key in R0 command

{"payload":"255,1234","instruction_type":"L0"}

S7 Scooter setting instruction 1 command: headlight switch ON, mode high speed, throttle ignore, taillights flashing shut down

{"payload":"1,3,0,1","instruction_type":"S7"}
