Gosafe G6C

Gosafe G6C is a quad-band GSM/GPRS/LTE tracking device perfectly suitable for a variety of applications: fleet management, insurance telematics, dispatch, vehicle location and recovery, and more. The device features multiple input & output, GSM jamming detection, RS232 serial port, geo-fencing, etc.

Protocol: gosafe Manufacturer: Gosafe Forum discussion
Properties
ADC data bitmask
adc_data
Determine the ADC parameters that will come from device.
adc1: ADC1 Voltage
adc2: ADC2 Voltage
backup_battery: Backup Battery
external_power: External Power
COT data bitmask
cot_data
Determine the COT parameters that will come from device.
in0: IN0 frequency/pulse data
in1: IN1 frequency/pulse data
in2: IN2 frequency/pulse data
in3: IN3 frequency/pulse data
mileage: Mileage
engine_hours: Engine hours
DTT data bitmask
dtt_data
Determine the device status data that will come from device.
io_status: I/O Status
packet_type: Packet Type Indicator
event_status: Event Status
device_status: Device Status
high36_geofences: High 36 Geofences Status
low120_geofences: Low 120 Geofences Status
Report Interval of Dynamic Mode
dynamic_report_interval
GPRS server report interval of mode1 (dynamic). Valid only when report interval switching mode is enabled. See "Report interval mode switching condition" setting
interval: Report interval
time_unit: Report interval time unit
data_format: Data format
report_mode: Report mode
Connectivity Setup
gprs_setup
GPRS Setup.
gprs: GPRS Communication Properties
server: Backend Server Communication Properties
GPS data bitmask
gps_data
Determine the GPS parameters that will come from device.
hdop: HDOP
vdop: vdop
speed: Speed
course: Azimuth
lat_lon: Latitude and Longitude
altitude: Altitude
sats_num: Valid satellites number
GSM data bitmask
gsm_data
Determine the GSM parameters that will come from device.
bs1: First Base Station
bs2: Second Base Station
bs3: Third Base Station
bs4: Fourth Base Station
bs5: Fifth Base Station
bs6: Sixth Base Station
bs7: Seventh Base Station
signal_lvl: Registration Status and CSQ Signal Level
Heartbeat Interval
heartbeat_interval
Setup Heartbeat Packet Interval. Set up the heartbeat packet uploading time interval of TCP/UDP sever, keep the sever and device connected.
interval: Interval
Report interval mode switching condition
report_interval_mode_switching
Report interval switching condition. Set up conditions when to switch from static to dynamic report mode.
stop: Stop
acc_off: ACC is off
backup_battery: Backup battery usage
domestic_roaming: Domestic roaming
international_roaming: International roaming
Report Interval of Static Mode
static_report_interval
GPRS server report interval of mode0 (static).
interval: Report interval
time_unit: Report interval time unit
data_format: Data format
report_mode: Report mode
System data bitmask
system_data
Determine the system parameters that will come from device.
fw_version: Firmware version
hw_version: Hardware version
device_name: Device name
